Air Ministry Chart Table Plotter, Mk.1 (6B/232): A brass navigational aid with a Perspex rule used to plot positions on maps, with the King's Crown Air Ministry mark. |
|
Medium landing compass No 1167 K.H.I/54. Undated but WW11 era. Used on a tripod for laying out landmarks and survey work on runways. |
|
Air Ministry P8 compass in its original box. Compering it to the P11, I cannot see any difference between them? |
|
Air Ministry P11 compass dated 1944. Used in a verity of Aircraft during WW11
Including Spitfires and Hurricanes. |
|
A.M. Douglas Combined Protractor & Parallel Rule. |
|
R.A.F. 06.A. Hand Bearing Compass. Undated. The compass casing is solid brass with a wooden handle and a brass light swich, the base of the torch unscrews for the battery or batteries to slip in. the markings on the top are
HAND BEARING
HUGES & SONS LTD LONDON
TYPE "06" No 089
MADE IN ENGLAND. |
|
The 06.A. is a hand-held compass, used by an observer to take navigational bearings in situations where a fixed compass could not be used, The handle holds batteries to power an internal lamp, which internally illuminates the bowl of the compass. With the bearing target sighted through the "V" atop the glass prism, the observer would read the direction of the bearing through the prism mirror as it is reflected up from the compass card. The markings on the compass card are reversed so that they appear correctly in the prism mirror. |
|
WW1 Officers compass made by F-L? dated 1917. The leather case dated 1916 . |
|
ww11 Officers compass made by T G & Co Ltd London dated 1940, no case |
|
compass magnetic marching MK.1. Undated made by T G & Co Ltd. with pattern 1937 compass case. |
|
NAVIGATIONAL COMPUTER / MK III D REF No.6B/180
The MK.III D navigational computer is a dead reckoning computer, it would have been strapped to the leg of a fighter pilot or on the navigator's table of a bomber. Undated, but the mark "I. C. A. N."
Stood for the International Convention on Aerial Navigation which operated from 1903 to 1945 it then became the International Civil Aviation Organization (ICAO). So it's probably World War Two era. |
|
Navigator’s dividers dated for 1944. A set of dividers is one of the navigator’s most
Essential tools, the dividers were critical for accessing distances and plotting courses on the charts. |
|
Navigator's Parallel Rule dated 1944. 'Capt. Field's Improved' boxwood parallel rule
With brass fittings. Used by the Navigator for route plotting in bomber aircraft. |
|
| A.M. Bubble Sextant Mk IX dated 1940. Introduced in 1938 and widely
Used by the Royal Air Force during World War II. Unfortunately the eyepiece has perished over the
Years so is no longer there, normally these came in a pressed board case but this one case in
Aluminium so possibly a later replaced case?
|
American WW11 computer true airspeed. |
MK11 Astro compass and base.
All the information I have so far is that it was probably made by an American company called Sperti in WW11
And was used by the RAF as well as the American air force. I have included a picture of it being used
In a B-25 Mitchell. I am assuming that the base stays in the aircraft as they are a separate item.
|
